Chain Link Gate Arm Hinge, Pressed Steel, Galvanized - Multiple Sizes

Product Description

Chain Link Gate Arm Hinge — Pressed Steel, Galvanized, 180° Swing (Multiple Post Sizes)

• Commercial/Industrial Grade Hinge: Pressed steel body with a heavy galvanized coating for long service life
• Built for Swing & Double-Drive Gates: Ideal where wide openings and frequent operation are required
• True 180° Gate Swing: Achieve a full opening arc without separate adapters
• Adjustable Fit: U-bolts clamp to 1-5/8″ or 2″ gate uprights for precise alignment
• Sized for Big Posts: Multiple post sizes available up to 6-5/8″ O.D.

This pressed steel arm hinge is a contractor-grade solution for commercial chain link swing gates and double-drive gates. The galvanized finish resists weathering, while the arm design works with a post-mounted hinge to allow a full 180° swing—maximizing clear opening for vehicles and equipment. Adjustable U-bolts on the gate side simplify installation and fine-tuning on 1-5/8″ or 2″ uprights. Use two hinges for most single gates; large or heavy leaves may require three.

Why Choose This Arm Hinge

• Full Opening Arc: 180° swing helps maximize access width and traffic flow
• Retrofit-Friendly: U-bolt design simplifies alignment and future adjustments
• Durable Build: Pressed steel with galvanized coating stands up to frequent cycling and outdoor exposure
• Flexible Sizing: Options to match common commercial post diameters up to 6-5/8″
• Simple Planning: Sold individually—order two (or three) per gate leaf as needed

Specifications

Buying Guide

• Match Post Size: Choose the arm hinge size that matches your post O.D. (e.g., 2-1/2″ → 2-3/8″ O.D.; 3″ → 2-7/8″ O.D.; 3-1/2″ → 3-1/2″ O.D.; 4″ → 4.00″ O.D.; 4-1/2″ → 4.50″ O.D.; 6-5/8″ → 6.625″ O.D.).
• Check Frame O.D.: Gate-side U-bolts clamp to 1-5/8″ or 2″ uprights (many 2″ frames are 1-7/8″ actual).
• Plan Hinge Count: Most single leaves use two hinges; tall/heavy gates may require three. Double drives use two hinges per leaf.
• Verify 180° Clearance: Ensure the gate can rotate alongside the fence line without striking obstacles when fully opened.

Frequently Asked Questions

Does this hinge allow a full 180° swing?

Yes. When paired with an appropriate post hinge and installed with proper clearance, the arm hinge enables 180° gate swing.

What gate frame sizes does it fit?

The gate-side U-bolts fit 1-5/8″ or 2″ uprights (commonly 1-7/8″ actual for many 2″ frames).

How many hinges do I need?

Use two per gate leaf in most cases; large or heavy gates may require three.

Is welding required?

No. The hinge clamps with U-bolts for secure mounting and easy adjustment.

What projects is this best for?

Commercial swing gates and double-drive gates where maximum opening and durability are important.

Comparison to Other Solutions

• Pressed Steel vs. Malleable Steel Arm Hinges: Both styles are galvanized and designed for heavy use; selection often comes down to project preferences and matching existing hardware.
• Arm Hinge vs. 180° Adapters: Hinge Adapters can retrofit 90° hinge setups to 180°; arm hinges provide 180° swing out of the box with fewer parts.
• Arm Hinge vs. Bulldog/Butt/Box Hinges: Bulldog/butt/box hinges typically swing ~90°; arm hinges are intended for full 180° operation.
